Hyflex 35

Maximum resistance to rotation.
Suitable for use on single part and multi-part hoist reeving systems.
Construction offers maximum resistance to wear.
Optional plastic impregnation (P) signifies full plastic impregnation of the rore.
Fully lubricated in manufacturing.

Hyflex 35

Standard Characteristics Hyflex 35
Compacted	Yes	No
Compacted		■
Grade	1960	2160
Grade	■	■
Finish	Bright	Galvanised
Finish		■
Lay Direction	Right Hand	Left Hand
Lay Direction	■
Lay Type	Ordinary	Langs
Lay Type	■	■
Nominal Fill Factor	0.635
Turn value at 20% of Breaking force degrees/ ‘6d’	0.2
Discard Criteria	Refer to ISO 4309:2019

NOMINAL ROPE DIAMETER		APPROX. MASS	MINIMUM BREAKING FORCE
			GALVANISED & UNGALVANISED
			ROPE GRADE
			1960		2160
mm	in	kg/100m	kN	tonnes	kN	tonnes
10		44.8	76	7.7	86.5	8.8
11		54.2	91	9.3	104	10.6
12		64.5	107	10.9	125	12.7
	1/2	72.0	123	12.5	137	14.0
13		76.0	128	13.0	146	14.9
14		88.0	148	15.1	168	17.1
16	5/8	115	194	19.8	221	22.5
18		145	242	24.7	277	28.2
19	3/4	162	277	28.2	312	31.8
20		179	301	30.7	337	34.4
21		198	335	34.1	370	37.7
22		217	370	37.7	412	42.0
	7/8	221	376	38.3	418	42.6
24		258	441	45.0	498	50.8
	1	289	491	50.1	546	55.7
26		303	517	52.7	581	59.2
28		351	599	61.1	681	69.4
	1-1/8	366	621	63.3	704	71.8
30		403	679	69.2	775	79.0
32	1-1/4	459	769	78.4	865	88.2
35	1-3/8	549	945	96.3	1044	106
36		581	983	100	1085	111
38	1-1/2	647	1078	110	1205	123
40		717	1202	123	1335	136
42		790	1227	125	1352	138
44		867	1347	137	1484	151
	1-3/4	885	1375	140	1515	155
46		948	1472	150	1622	165
48		1032	1603	163	1766	180
50		1120	1740	177	1917	195
	2	1156	1796	183	1979	202
52		1211	1881	192	2072	211

* Mass per unit length of HYFLEX 35P increases by approx. 3%

Note: HYFLEX 35P is available on special request and prior confirmation.
Rope Sizes and Breaking Force not shown in the standard table, may be available on request and prior confirmation.
