Pressure & Temperature Switch

PRESSURE SWITCHES

Pressure Switch - Standard

PI-S101

Commercial pressure switch

Pressure Switch - Standard

  • Repeatability :± 2% F.S.
  • Sensing Elements :Phosphor Bronze Bellow
  • Switch :1 SPDT, 15A,220 VAC / 10A,24 VDC
  • Mounting :Bottom / Panel
  • Enclosure Material :Steel (plated) with Plastic cover
PI-S102

Weatherproof pressure switch, adjustable differential

Pressure Switch - Standard

  • Repeatability :± 2% F.S.
  • Sensing Elements :Phosphor Bronze / Stainless Steel Bellows
  • Switch :1 SPDT, 15A,220 VAC / 10A,24 VDC
  • Mounting :Bottom / Panel
PI-S103

Miniature pressure switch

Pressure Switch - Standard

  • Repeatability :± 2% F.S.
  • Sensing Elements :SS Diaphragm
  • Switch :1 SPST, 5A,220 VAC / 10A,24 VDC
  • Mounting :Direct
  • Enclosure Material :Stainless Steel
PI-S104

Miniature pressure switch, internal adjustment

Pressure Switch - Standard

  • Repeatability :± 1% F.S.
  • Sensing Elements :SS 316 Diaphragm
  • Switch :1 SPDT, 5A,250 VAC / 0.2A,24 VDC
  • Mounting :Bottom / Panel
  • Enclosure Material :Aluminum pressure die cast
PI-S105

Miniature pressure switch, OEM industry

Pressure Switch - Standard

  • Repeatability :± 1% F.S.
  • Sensing Elements :SS Diaphragm
  • Switch :1 or 2 SPDT, 5A,220 VAC / 10A,24 VDC
  • Mounting :Direct
  • Enclosure Material :Stainless Steel

Pressure Switch - Weather proof series

PI-S201

Weatherproof pressure switch, high accuracy & repeatability type

Pressure Switch - Weather proof series

  • Repeatability :± 0.5% F.S.
  • Sensing Elements :AISI 316 SS, Diaphragm
  • Switch :1 SPDT, 15A,250 VAC / 2A,24 VDC (Others on request)
  • Mounting :Bottom / Panel
PI-S202

Differential pressure switch

Pressure Switch - Weather proof series

  • Repeatability :± 0.5% F.S.
  • Sensing Elements :AISI 316 SS, Diaphragm
  • Switch :1 SPDT, 15A,250 VAC / 2A,24 VDC (Others on request)
  • Mounting :Bottom / Panel
  • Enclosure Material :Aluminum pressure die cast
PI-S203

High pressure switch

Pressure Switch - Weather proof series

  • Repeatability :± 1% F.S.
  • Sensing Elements :AISI 316 SS, Piston
  • Switch :1 SPDT, 15A,250 VAC / 2A,24 VDC (Others on request)
  • Mounting :Bottom / Panel
  • Enclosure Material :Aluminum pressure die cast

Pressure Switch - Flame proof series

PI-S301

Flame proof pressure switch, high accuracy & repeatability

Pressure Switch - Flame proof series

  • Repeatability :± 0.5% F.S.
  • Sensing Elements :AISI 316 SS, Diaphragm
  • Switch :1 SPDT, 15A,250 VAC / 2A,24 VDC (Others on request)
  • Mounting :Bottom / Panel
PI-S302

Flame proof differential pressure switch

Pressure Switch - Flame proof series

  • Repeatability :± 0.5% F.S.
  • Sensing Elements :AISI 316 SS, Diaphragm
  • Switch :1 SPDT, 15A,250 VAC / 2A,24 VDC (Standard)
  • Mounting :Bottom / Panel
PI-S303

Flame proof high pressure switch

Pressure Switch - Flame proof series

  • Repeatability :± 1% F.S.
  • Sensing Elements :AISI 316 SS, Piston
  • Switch :1 SPDT, 15A,250 VAC / 2A,24 VDC (Others on request)
  • Mounting :Bottom / Panel
  • Enclosure Material :Aluminum pressure die cast

Temperature Switches

Temperature - Switches - Gas filled systems

PI-T703

PI Controls Europe - Industrial thermometer, with electrical contact

Switches - Gas filled systems

  • Dial size :DN100/DN150
  • Range :-100…800°C
  • Stem size :6.0 mm to 12 mm
  • Assembly :Direct or Remote
PI-T704

PI Controls Europe - Temperature switch, weatherproof

Switches - Gas filled systems

  • Repeatability :± 2% F.S.
  • Sensing Elements :AISI 316 SS
  • Switch :1 SPDT, 15A,250 VAC / 2A,24 VDC (Others on request)
  • Mounting :Direct / Remote
PI-T705

PI Controls Europe - Temperature switch, ex-proof

Switches - Gas filled systems

  • Repeatability :± 2% F.S.
  • Sensing Elements :AISI 316 SS
  • Switch :1 SPDT, 15A,250 VAC / 2A,24 VDC (Others on request)
  • Mounting :Direct / Remote
PI-T708

PI Controls Europe - Industrial thermometer, with electrical contact, Dome style

Switches - Gas filled systems

  • Dial size :DN100 / DN150
  • Range :-100…800°C
  • Stem size :6.0 mm to 12 mm
  • Assembly :Direct or Remote
