Hyflex 8P

Hyflex 8P is a flexible high strength eight strand steel wire rope with plastic impregnated core.
Good bending fatigue life.
Greater surface contact area resulting from the eight strand construction.
Fully lubricated in manufacturing.
Optional plastic impregnation of the steel core. (P) signifies full plastic impregnation of the steel core.

Hyflex 8P

Standard Characteristics Hyflex 8/8P
Compacted	Yes	No
Compacted		■
Grade	1960	2160
Grade		■
Finish	Bright	Galvanised
Finish	■	■
Lay Direction	Right Hand	Left Hand
Lay Direction	■	■
Lay Type	Ordinary	Langs
Lay Type	■
Nominal Fill Factor	0.598
Turn value at 20% of Breaking force degrees/ ‘6.5d’	87
Discard Criteria	Refer to ISO 4309:2019

Warning: Hyflex 8/8P in Langs lay must only be used in applications where both ends are secured and are unable to rotate.

NOMINAL ROPE DIAMETER		APPROX. MASS	MINIMUM BREAKING FORCE
			GALVANISED & UNGALVANISED
			ROPE GRADE
			1960		2160
mm	in	kg/100m	kN	tonnes	kN	tonnes
10		43.5	72.9	7.4	81.4	8.3
11		52.6	86.1	8.8	96.5	9.8
12		62.6	105	10.7	117	11.9
	1/2	70.2	123	12.5	131	13.4
13		73.5	124	12.6	138	14.1
14		85.3	143	14.6	160	16.3
15		97.9	164	16.7	183	18.7
16	5/8	111	187	19.1	208	21.2
17		126	211	21.5	239	24.4
18		141	239	24.4	267	27.2
19	3/4	157	269	27.4	300	30.6
20		174	295	30.1	331	33.7
22		211	356	36.3	400	40.8
	7/8	215	360	36.7	402	41.0
24		251	423	43.1	475	48.4
	1	281	470	47.9	525	53.5
26		297	500	51.0	562	57.3
28		345	572	58.3	642	65.4
	1-1/8	359	596	60.8	665	67.8
30		396	656	66.9	733	74.7
32	1-1/4	451	747	76.1	836	85.2
34		509	843	85.9	945	96.3
36		570	935	95.3	1053	107
38	1-1/2	635	1043	106	1172	119
40		704	1162	118	1313	134
42		785	1305	133	1462	149
44		862	1412	144	1577	161
	1-3/4	879	1441	147	1613	164
46		942	1543	157	1731	176
48		1025	1680	171	1885	192
50		1113	1833	187	2065	210
	2	1148	1882	192	2101	214
52		1203	1972	201	2202	224

* Mass per unit length of HYFLEX 8P increases by approx. 3%

Note: Rope Sizes and Breaking Force not shown in the standard table, may be available on request and prior confirmation.
HYFLEX 8P ia available for rope diameter 16 mm and above on special request and prior confirmation.
