What steam trap types are manufactured by Pennant and supplied by Gulf Oil & Gas International?

Gulf Oil & Gas International distributes the complete genuine Pennant product line, including Thermodynamic Steam Traps (PT11, PT13, PT14N, PT17R), Ball Float Steam Traps with steam lock release (PT61S, PT62S, PT65S, PT65H, PT62HP), Inverted Bucket Steam Traps (PT21, PT23, PT24, PT25L), Sanitary Clean Steam Thermostatic Traps (PT32), and Liquid Drain / Auto Drain Traps (PD61, PD62) for compressed air and gas systems.

What is the delivery turnaround and stock availability for Pennant products?

Gulf Oil & Gas International maintains a comprehensive ready inventory in the UAE covering standard IBR and Non-IBR models, enabling immediate dispatch within 24 to 48 hours to project sites and industrial plants across the Middle East, Africa, and CIS regions.

What is the working function of Pennant Liquid Drain Traps (PD61 and PD62)?

Pennant PD61 and PD62 liquid drain traps are designed specifically for compressed air and industrial gas systems. They use a float-operated mechanism to automatically discharge accumulated moisture, oil, and liquid condensate from receivers, separators, and piping drops without releasing expensive compressed air or gas.

What pressure and temperature ratings are supported across the thermodynamic range?

Pennant thermodynamic traps range from the standard PT11 (up to 42 bar, CA40 stainless steel) to high-pressure alloy models such as the PT13 (up to 65 bar, ASTM A217 Gr. WC6) and PT14N (up to 92 bar, ASTM A182 Gr. F22 CL3, for superheated steam up to 537°C), as well as forged carbon steel PT17R (up to 50 bar, ASTM A105).

What certifications and approvals accompany Pennant steam traps?

Pennant steam traps and liquid drain traps are fully certified to IBR (Indian Boiler Regulations with Form III-C certificates), CE Pressure Equipment Directive (PED), UL requirements, and ISO 9001:2015 quality standards, with complete EN 10204 3.1 material test certificates.

Which geographic markets are supported for supply and technical support?

Supply and engineering support cover the UAE, Saudi Arabia, Qatar, Kuwait, Oman, Bahrain, Iraq, Egypt, Algeria, Morocco, Tunisia, Libya, Nigeria, Angola, Ghana, Ivory Coast, Senegal, Mauritania, Gabon, Congo, Cameroon, Equatorial Guinea, DR Congo, Kenya, Tanzania, Mozambique, Uganda, Ethiopia, Rwanda, Zambia, Zimbabwe, Botswana, South Africa, Namibia, Kazakhstan, Azerbaijan, Uzbekistan, and Turkmenistan. Distribution strictly excludes Iran, Palestine, Israel, and Russia.

Pennant Steam Traps & Liquid Drain Traps

Gulf Oil & Gas International distributes genuine Pennant Steam Traps and LIQUID DRAIN TRAPS. We maintain comprehensive ready stock across the complete product range—Thermodynamic, Ball Float, Inverted Bucket, Clean Steam, and Liquid Drain Traps—guaranteeing superior stock availability and fast supply across the Middle East, Africa, and CIS.

✔ Genuine Pennant Product Line ✔ IBR Certified (Form III-C) & Non-IBR ✔ CE Certified Compliance ✔ UL Listed Quality Standards ✔ ISO 9001:2015 Certified System ✔ Immediate Ready Stock in UAE Hub

✉ Request Official Quotation & Stock Availability 💬 Instant WhatsApp Procurement

Pennant Trap Technologies & Operating Principles

Pennant steam traps and liquid drain traps are engineered to maximize plant thermal efficiency, eliminate live steam losses, protect process pipelines from water hammer, and automatically purge condensate from steam and compressed gas headers.

Thermodynamic Steam Traps

Compact, rugged disc traps engineered for steam mainline drainage, tracing lines, and high-pressure superheated steam systems.

Operating Principle: Uses kinetic energy and flash steam velocity beneath the disc
Key Models: PT11 (CA40 SS up to 42 bar), PT13 (WC6 up to 65 bar), PT14N (F22 up to 92 bar), PT17R (A105 up to 50 bar)
Integral Protection: Built-in AISI 304 strainer screen for dirt and scale protection
Durability: Water hammer resistant, freeze-proof, and compact installation

Ball Float Steam Traps

Continuous modulating condensate discharge traps ideal for temperature-controlled heat exchangers and high-load process vessels.

Operating Principle: Pure buoyancy mechanism tracking live condensate formation
Key Models: PT61S (Cast Iron), PT62S / PT62HP (Cast Steel WCB), PT65S / PT65H (Cast Iron)
Key Features: Built-in thermostatic air vent and Steam Lock Release (SLR) mechanism
Pressure Classes: Differential pressures from 4.5 bar, 10 bar, to 14 bar

Inverted Bucket & Liquid Drain Traps

Heavy-duty mechanical traps for severe industrial steam services and compressed air moisture removal.

Inverted Bucket Traps: Models PT21, PT23, PT24 (WCB up to 63 bar), and PT25L (WCB up to 25 bar)
Liquid Drain Traps: Models PD61 (Cast Iron) and PD62 (Cast Steel) for compressed air and gas lines
Air & Gas Protection: Discharges liquids continuously without compressed gas loss
Clean Steam Trap: Model PT32 in SS 316L with sanitary Tri-Clamp connections

Complete Ready Inventory Matrix (Immediate UAE Supply)

Gulf Oil & Gas International maintains active inventory across all models, sizes, materials of construction (MOC), and pressure ratings detailed below for fast shipment:

1. Thermodynamic Steam Traps

Size	Description	MOC (Body Material)	IBR / Non-IBR	End Connection	Model	Pressure Rating	Make
15MM (1/2")	PT11 Thermodynamic Steam Trap	CA40 Gr. Stainless Steel	IBR	Screwed	PT11	Up to 42 Kg (42 Bar)	Pennant
15MM (1/2")	PT11 Thermodynamic Steam Trap	CA40 Gr. Stainless Steel	IBR	Socket Weld	PT11	Up to 42 Kg (42 Bar)	Pennant
20MM (3/4")	PT11 Thermodynamic Steam Trap	CA40 Gr. Stainless Steel	IBR	Screwed	PT11	Up to 42 Kg (42 Bar)	Pennant
20MM (3/4")	PT11 Thermodynamic Steam Trap	CA40 Gr. Stainless Steel	IBR	Socket Weld	PT11	Up to 42 Kg (42 Bar)	Pennant
20MM (3/4")	PT11 Thermodynamic Steam Trap	CA40 Gr. Stainless Steel	Non-IBR	Screwed	PT11	Up to 42 Kg (42 Bar)	Pennant
20MM (3/4")	PT11 Thermodynamic Steam Trap	CA40 Gr. Stainless Steel	Non-IBR	Socket Weld	PT11	Up to 42 Kg (42 Bar)	Pennant
25MM (1")	PT11 Thermodynamic Steam Trap	CA40 Gr. Stainless Steel	IBR	Screwed	PT11	Up to 42 Kg (42 Bar)	Pennant
25MM (1")	PT11 Thermodynamic Steam Trap	CA40 Gr. Stainless Steel	Non-IBR	Screwed	PT11	Up to 42 Kg (42 Bar)	Pennant
15MM (1/2")	PT13 Thermodynamic Steam Trap	ASTM A217 Gr. WC6 Alloy Steel	IBR	Socket Weld	PT13	Up to 65 Kg (65 Bar)	Pennant
20MM (3/4")	PT13 Thermodynamic Steam Trap	ASTM A217 Gr. WC6 Alloy Steel	IBR	Socket Weld	PT13	Up to 65 Kg (65 Bar)	Pennant
20 x 25MM	PT13 Thermodynamic Steam Trap	ASTM A217 Gr. WC6 Alloy Steel	IBR	Socket Weld	PT13	Up to 65 Kg (65 Bar)	Pennant
15MM (1/2")	PT14N Thermodynamic Steam Trap	ASTM A182 Gr. F22 CL3 Alloy Steel	IBR	Socket Weld	PT14N	Up to 92 Kg (92 Bar)	Pennant
20MM (3/4")	PT14N Thermodynamic Steam Trap	ASTM A182 Gr. F22 CL3 Alloy Steel	IBR	Socket Weld	PT14N	Up to 92 Kg (92 Bar)	Pennant
25MM (1")	PT14N Thermodynamic Steam Trap	ASTM A182 Gr. F22 CL3 Alloy Steel	IBR	Socket Weld	PT14N	Up to 92 Kg (92 Bar)	Pennant
20MM (3/4")	PT17R Thermodynamic Steam Trap	ASTM A105 Forged Carbon Steel	Non-IBR	Socket Weld	PT17R	50 Bar	Pennant
25MM (1")	PT17R Thermodynamic Steam Trap	ASTM A105 Forged Carbon Steel	IBR	Socket Weld	PT17R	50 Bar	Pennant
25MM (1")	PT17R Thermodynamic Steam Trap	ASTM A105 Forged Carbon Steel	Non-IBR	Socket Weld	PT17R	50 Bar	Pennant

2. Sanitary & Clean Steam Thermostatic Traps

Size	Description	MOC (Body Material)	IBR / Non-IBR	End Connection	Model	Pressure Rating	Make
15MM (1/2")	PT32 Thermostatic Clean Steam Trap	Stainless Steel 316L	Non-IBR	Tri-Clamp Sanitary End	PT32	10.5 Bar	Pennant

3. Ball Float Steam Traps (with Steam Lock Release)

Size	Description	MOC (Body Material)	IBR / Non-IBR	End Connection	Model	Pressure Rating	Make
15MM (1/2")	PT61S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT61S	4.5 Bar	Pennant
15MM (1/2")	PT61S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT61S	10 Bar	Pennant
20MM (3/4")	PT61S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT61S	4.5 Bar	Pennant
20MM (3/4")	PT61S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT61S	10 Bar	Pennant
25MM (1")	PT61S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT61S	4.5 Bar	Pennant
25MM (1")	PT61S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT61S	10 Bar	Pennant
25MM (1")	PT65S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT65S	4.5 Bar	Pennant
25MM (1")	PT65S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT65S	10 Bar	Pennant
25MM (1")	PT65S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT65S	14 Bar	Pennant
40MM (1-1/2")	PT65S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT65S	4.5 Bar	Pennant
40MM (1-1/2")	PT65S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT65S	10 Bar	Pennant
50MM (2")	PT65S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT65S	4.5 Bar	Pennant
50MM (2")	PT65S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT65S	10 Bar	Pennant
50MM (2")	PT65S Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT65S	14 Bar	Pennant
50MM (2")	PT65H Ball Float Steam Trap	Cast Iron	Non-IBR	Screwed	PT65H	4.5 Bar	Pennant
15MM (1/2")	PT62S Ball Float Steam Trap	Cast Steel (ASTM A216 WCB)	IBR	Screwed	PT62S	10 Bar	Pennant
15MM (1/2")	PT62S Ball Float Steam Trap	Cast Steel (ASTM A216 WCB)	IBR	Socket Weld	PT62S	4.5 Bar	Pennant
15MM (1/2")	PT62S Ball Float Steam Trap	Cast Steel (ASTM A216 WCB)	IBR	Socket Weld	PT62S	10 Bar	Pennant
15MM (1/2")	PT62S Ball Float Steam Trap	Cast Steel (ASTM A216 WCB)	IBR	Socket Weld	PT62S	14 Bar	Pennant
20MM (3/4")	PT62S Ball Float Steam Trap	Cast Steel (ASTM A216 WCB)	IBR	Screwed	PT62S	4.5 Bar	Pennant
20MM (3/4")	PT62S Ball Float Steam Trap	Cast Steel (ASTM A216 WCB)	IBR	Screwed	PT62S	10 Bar	Pennant
20MM (3/4")	PT62S Ball Float Steam Trap	Cast Steel (ASTM A216 WCB)	IBR	Socket Weld	PT62S	4.5 Bar	Pennant
20MM (3/4")	PT62S Ball Float Steam Trap	Cast Steel (ASTM A216 WCB)	IBR	Socket Weld	PT62S	10 Bar	Pennant
25MM (1")	PT62S Ball Float Steam Trap	Cast Steel (ASTM A216 WCB)	Non-IBR	Screwed	PT62S	4.5 Bar	Pennant
25MM (1")	PT62S Ball Float Steam Trap	Cast Steel (ASTM A216 WCB)	IBR	Screwed	PT62S	10 Bar	Pennant
25MM (1")	PT62S Ball Float Steam Trap	Cast Steel (ASTM A216 WCB)	IBR	Socket Weld	PT62S	4.5 Bar	Pennant
25MM (1")	PT62HP Ball Float Steam Trap	Cast Steel (ASTM A216 WCB)	IBR	Screwed	PT62HP	High Pressure	Pennant
40MM (1-1/2")	PT62S Ball Float Steam Trap	Cast Steel (ASTM A216 WCB)	IBR	Socket Weld	PT62S	10 Bar	Pennant

4. Inverted Bucket Steam Traps

Size	Description	MOC (Body Material)	IBR / Non-IBR	End Connection	Model	Pressure Rating	Make
15MM (1/2")	PT21 Inverted Bucket Steam Trap	Cast Iron	Non-IBR	Screwed	PT21	17 Bar	Pennant
20MM (3/4")	PT21 Inverted Bucket Steam Trap	Cast Iron	Non-IBR	Screwed	PT21	17 Bar	Pennant
25MM (1")	PT21 Inverted Bucket Steam Trap	Cast Iron	Non-IBR	Screwed	PT21	9 Bar	Pennant
40MM (1-1/2")	PT21 Inverted Bucket Steam Trap	Cast Iron	Non-IBR	Screwed	PT21	2 Bar (8.7 Bar)	Pennant
15MM (1/2")	PT23 Inverted Bucket Steam Trap	Cast Iron	Non-IBR	Screwed	PT23	16 Bar	Pennant
20MM (3/4")	PT23 Inverted Bucket Steam Trap	Cast Iron	Non-IBR	Screwed	PT23	16 Bar	Pennant
25MM (1")	PT23 Inverted Bucket Steam Trap	Cast Iron	Non-IBR	Screwed	PT23	2 Bar	Pennant
25MM (1")	PT24 Inverted Bucket Steam Trap	ASTM A216 Gr. WCB Cast Steel	IBR	Socket Weld	PT24	63 Bar	Pennant
25MM (1")	PT25L Inverted Bucket Steam Trap	ASTM A216 Gr. WCB Cast Steel	Non-IBR	Screwed	PT25L	25 Bar	Pennant

5. Liquid Drain Traps & Auto Drain Traps (Compressed Air & Gas Systems)

Size	Description	MOC (Body Material)	IBR / Non-IBR	End Connection	Model	Pressure Rating	Make
15MM (1/2")	PD61 Liquid Drain Trap	Cast Iron	Non-IBR	Screwed	PD61	4.5 Bar	Pennant
15MM (1/2")	PD61 Liquid Drain Trap	Cast Iron	Non-IBR	Screwed	PD61	10 Bar	Pennant
15MM (1/2")	PD61 Liquid Drain Trap	Cast Iron	Non-IBR	Screwed	PD61	14 Bar	Pennant
20MM (3/4")	PD61 Liquid Drain Trap	Cast Iron	Non-IBR	Screwed	PD61	4.5 Bar	Pennant
20MM (3/4")	PD61 Liquid Drain Trap	Cast Iron	Non-IBR	Screwed	PD61	10 Bar	Pennant
20MM (3/4")	PD61 Liquid Drain Trap	Cast Iron	Non-IBR	Screwed	PD61	14 Bar	Pennant
25MM (1")	PD61 Liquid Drain Trap	Cast Iron	Non-IBR	Screwed	PD61	4.5 Bar	Pennant
25MM (1")	PD61 Liquid Drain Trap	Cast Iron	Non-IBR	Screwed	PD61	10 Bar	Pennant
15MM (1/2")	PD62 Liquid Drain Trap	Cast Steel (ASTM A216 WCB)	Non-IBR	Socket Weld	PD62	10 Bar	Pennant
25MM (1")	PD62 Liquid Drain Trap	Cast Steel (ASTM A216 WCB)	Non-IBR	Socket Weld	PD62	4.5 Bar	Pennant

Industries & Sectors Powered by Pennant Traps

Pennant steam traps and liquid drain traps are installed across heavy industry, energy, chemical, and utility infrastructures worldwide.

Thermal Power Generation

Main steam header drainage, superheater startup drains, turbine casing extraction lines, reheat headers, and auxiliary steam lines.

Oil Refining & Petrochemicals

Viscous hydrocarbon line steam tracing, crude preheater steam battery drainage, reboilers, and flare knockout drum auto-drain traps.

Chemical & Fertilizer Plants

Continuous condensate drainage on urea reactors, ammonia synthesis heaters, sulfuric acid reboilers, and multi-effect evaporators.

Textile Processing & Dyeing

Stenter machines, multi-cylinder sizing drying ranges, high-pressure fabric dyeing autoclaves, and garment steam presses.

Food, Dairy & Beverage

Plate heat exchangers, batch cookers, flash pasteurizers, clean-in-place (CIP) hot water loops, and brewery boiling kettles.

Pharmaceutical & Biotech

Pure steam lines, sanitary sterilizer autoclaves, clean utility loops, and distillation units using Pennant PT32 SS316L traps.

Pulp, Paper & Board Mills

Paper machine drying cylinders, corrugated box steam headers, digester steam jackets, and black liquor preheating.

Sugar Mills & Distilleries

Bagasse boiler mainlines, raw juice heaters, evaporator calandrias, vacuum pan drainage, and alcohol distillation columns.

Tire & Rubber Manufacturing

Tire curing presses, platen presses, vulcanizing autoclaves, tire mold heating circuits, and rubber compound mixers.

Compressed Air & Gas Utilities

Air receiver tanks, air compressor aftercoolers, refrigerated air dryers, moisture separators, and compressed air distribution ring mains.

Thermal Desalination Facilities

Multi-Stage Flash (MSF) and Multi-Effect Distillation (MED) brine heater condensate drainage and steam ejector loops.

District Steam & Central Utilities

Municipal steam distribution pipelines, campus steam tunnels, hospital heating networks, and laundry steam headers.

Process & Equipment Applications by Trap Type

Selecting the proper Pennant trap model ensures zero steam loss, prevents water hammer, and maximizes heat transfer efficiency.

Thermodynamic Traps (PT11, PT13, PT14N, PT17R)

High-pressure steam mainline drip legs & header pockets
Expansion loop collection drain pockets
Steam tracing lines for viscous fluids & freeze prevention
High-temperature superheated steam lines up to 537°C
Turbine bypass drains & boiler stop valve drains

Ball Float Traps (PT61S, PT62S, PT65S, PT65H)

Shell-and-tube heat exchangers & reboilers
Jacketed reactors & batch processing kettles
Air handling unit (AHU) steam heating coils
Evaporator calandrias & continuous drying rolls
Applications requiring Steam Lock Release (SLR)

Liquid Drain Traps (PD61, PD62)

Compressed air moisture separators & drop legs
Air compressor receiver tank bottom drainage
Refrigerated & desiccant air dryer drain points
Industrial gas distribution headers (nitrogen, CO2)
Automatic zero-gas-loss liquid drainage

Territorial Supply Coverage: Middle East, Africa & CIS

Gulf Oil & Gas International distributes genuine Pennant Steam Traps and Liquid Drain Traps with immediate warehouse stock, complete inspection documentation, and technical support across major industrial and energy hubs:

🇦🇪 United Arab Emirates

Dubai (JAFZA, DIPC), Abu Dhabi (ICAD, Mussafah, Ruwais, Habshan), Sharjah (Hamriyah), Ras Al Khaimah, Fujairah Port.

🇸🇦 Saudi Arabia (KSA)

Riyadh Industrial Cities, Jubail Industrial City, Dammam 1st & 2nd, Yanbu, Ras Tanura, Rabigh, Jazan Economic City.

🇶🇦 Qatar & 🇰🇼 Kuwait

Doha Industrial Area, Ras Laffan Industrial City, Mesaieed, Kuwait City (Shuwaikh), Ahmadi Refinery Hub, Mina Abdulla.

🇴🇲 Oman & 🇧🇭 Bahrain

Muscat (Rusayl), Sohar Port, Salalah Free Zone, Duqm Port, Manama (Hidd Industrial Area), Sitra BAPCO Hub.

🇮🇶 Iraq

Basra (Khor Al Zubair Port), Erbil, Baghdad, Rumaila Oilfield, West Qurna, Baiji Industrial Hub.

🇪🇬 Egypt

Cairo (10th of Ramadan), Alexandria (Borg El Arab), Suez Canal Economic Zone, Port Said, Ain Sokhna, Damietta.

🇩🇿 Algeria

Hassi Messaoud, Skikda Petrochemical, Arzew Gas Terminal, Algiers Industrial Zone, Oran, Bethioua.

🇲🇦 Morocco

Casablanca, Tanger Med Port & Free Zone, Jorf Lasfar Industrial Complex, Safi Chemical Hub, Rabat, Kenitra.

🇹🇳 Tunisia & 🇱🇾 Libya

Tunis, Sfax, Bizerte Refinery Hub, Gabes Chemical Zone, Tripoli, Benghazi, Misrata Port, Ras Lanuf Terminal, Marsa El Brega.

🇳🇬 Nigeria

Lagos (Lekki FTZ, Apapa), Port Harcourt (Onne Port), Warri Refinery, Bonny Island LNG, Calabar Free Trade Zone, Kaduna.

🇬🇭 Ghana & 🇨🇮 Ivory Coast

Accra, Takoradi Port & Energy Hub, Tema Industrial Area, Abidjan Port & Refining Hub, San Pedro Port.

🇸🇳 Senegal & 🇲🇷 Mauritania

Dakar Port, Saint-Louis Offshore Gas Basin, Mbour, Nouakchott Port, Nouadhibou Mining Port.

🇦🇴 Angola

Luanda, Cabinda Offshore Terminal, Soyo LNG Hub, Lobito Port & Refinery Development.

🇬🇦 Gabon & 🇨🇬 Congo

Libreville, Port-Gentil Oil Terminal, Pointe-Noire Offshore Hub, Brazzaville Industrial Area.

🇬🇶 Equatorial Guinea & 🇨🇲 Cameroon

Malabo, Punta Europa LNG, Bata, Douala Industrial Port, Kribi Deep Sea Port, Limbe Refinery.

🇨🇩 DR Congo

Kinshasa, Lubumbashi Mining Center, Kolwezi Copperbelt, Matadi Port, Boma.

🇰🇪 Kenya & 🇺🇬 Uganda

Nairobi, Mombasa Port & Kipevu Oil Terminal, Lamu Port, Kisumu, Kampala, Hoima Lake Albert Energy Basin.

🇹🇿 Tanzania & 🇲🇿 Mozambique

Dar es Salaam Port, Mtwara Gas Hub, Tanga, Maputo Port, Afungi LNG Hub, Pemba Oil & Gas Port, Beira.

🇪🇹 Ethiopia & 🇷🇼 Rwanda

Addis Ababa, Dire Dawa Industrial Park, Hawassa Industrial Park, Kigali Special Economic Zone, Bugesera.

🇿🇦 South Africa

Johannesburg, Durban Port, Cape Town, Richards Bay Coal & Gas Terminal, Saldanha Bay, Secunda Sasol Complex, Sasolburg.

🇳🇦 Namibia & 🇧🇼 Botswana

Windhoek, Walvis Bay Port, Luderitz Energy Hub, Gaborone Industrial Area, Francistown, Jwaneng.

🇿🇲 Zambia & 🇿🇼 Zimbabwe

Lusaka, Kitwe Copperbelt, Ndola Refinery, Harare, Bulawayo Industrial Zone, Hwange Power Station.

🇰🇿 Kazakhstan & 🇦🇿 Azerbaijan

Aktau Port, Atyrau Caspian Hub, Tengiz Field, Kashagan Offshore, Baku Shipyard, Sangachal Terminal, Sumqayit.

🇺🇿 Uzbekistan & 🇹🇲 Turkmenistan

Tashkent, Bukhara Refinery, Navoiy Free Industrial Zone, Fergana, Ashgabat, Turkmenbashi Port & Refinery.

Frequently Asked Questions (FAQ)

Technical, operational, and procurement details for genuine Pennant Steam Traps and Liquid Drain Traps.

Why choose genuine Pennant steam traps from Gulf Oil & Gas International?

Gulf Oil & Gas International provides certified, factory-fresh Pennant steam traps and liquid drain traps backed by extensive warehouse stock in Dubai. We offer immediate dispatch, full manufacturer warranties, IBR inspection certificates (Forms III-C), and expert sizing assistance to ensure rapid replacement and zero plant downtime.

What makes the Pennant PT11 thermodynamic trap suitable for fluctuating pressures?

The Pennant PT11 is engineered with an ASTM A743 Gr. CA40 stainless steel body, hardened stainless steel disc, and integrated AISI 304 strainer. It features concentric condensate entry beneath the disc, ensuring a clean and parallel disc lift without localized wear. The trap handles fluctuating loads and pressures up to 42 bar without adjustment and provides tight shut-off with zero steam loss.

How does the Steam Lock Release (SLR) unit in Pennant Ball Float Traps operate?

In applications like revolving drying cylinders or long pipe configurations, steam can become trapped in the pipe preceding the trap, preventing condensate from reaching the float chamber (steam locking). Pennant ball float traps (PT61S, PT62S, PT65S) feature a manually adjustable Steam Lock Release (SLR) needle valve that vents the locking steam, allowing condensate to enter and the trap to resume continuous drainage.

What is the key difference between steam traps and liquid drain traps (PD61/PD62)?

Steam traps are designed to retain live steam while discharging condensate. Liquid drain traps (PD61 and PD62), on the other hand, are engineered for compressed air and gas systems. They use a float mechanism to purge accumulated liquid water and oil emulsions from air receivers, drop legs, and gas piping without allowing expensive compressed air or process gas to escape.

What high-pressure options exist in Pennant's thermodynamic range?

For superheated and high-pressure steam headers, Pennant manufactures the PT13 in alloy steel ASTM A217 Gr. WC6 (rated up to 65 kg/cm²) and the PT14N in forged alloy steel ASTM A182 Gr. F22 CL3 (rated up to 92 kg/cm² and 537°C), both with socket weld connections and full IBR certification.

What end connections and certifications are provided?

Pennant traps are available with Screwed (NPT / BSP / BSPT), Socket Weld, Sanitary Tri-Clamp (PT32), and Flanged end connections. They are accompanied by IBR Form III-C inspection certificates, CE Pressure Equipment Directive (PED) documentation, UL compliance verification, and ISO 9001:2015 quality guarantees.

Procure Genuine Pennant Steam & Liquid Drain Traps

Submit your model requirements, sizes, operating pressures, and quantities for immediate stock verification and commercial quotation across Middle East, Africa, and CIS markets.

✉ Email: [email protected] 💬 WhatsApp: +971 55 638 1854
