Powerform 35

Maximum resistance to rotation.
Suitable for use on single part and multi-part hoist reeving systems.
High fatigue life resulting from the unique compaction process.
Increased resistance to crushing. Recommended for multi-layer spooling operations.
Increased abrasion resistance resulting from the unique compaction process.
Optional plastic impregnation. (P) signifies full plastic impregnation of the rope.
Fully lubricated in manufacturing.

Powerform 35

Standard Characteristics Powerform^® 35/35P
Compacted	Yes	No
Compacted	■
Grade	1960	2160
Grade	■	■
Finish	Bright	Galvanised
Finish	■	■
Lay Direction	Right Hand	Left Hand
Lay Direction	■	■
Lay Type	Ordinary	Langs
Lay Type		■
Nominal Fill Factor	0.745
Turn value at 20% of Breaking force degrees/ ‘6d’	0.2
Discard Criteria	Refer to ISO 4309:2019

Warning: Powerform^® 6/6P in Langs lay must only be used in applications where both ends are secured and are unable to rotate.

NOMINAL ROPE DIAMETER		APPROX. MASS	MINIMUM BREAKING FORCE
			GALVANISED & UNGALVANISED
			ROPE GRADE
			1960		2160
mm	in	kg/100m	kN	tonnes	kN	tonnes
	1/2	81.1	148	15.1	160	16.3
13		85.0	155	15.8	167	17.0
14		98.6	180	18.3	192	19.6
16	5/8	129	233	23.8	252	25.7
18		163	300	30.6	321	32.7
19	3/4	182	331	33.7	358	36.0
20		201	372	37.9	399	40.7
21		222	402	41.0	434	44.2
22		243	444	45.3	484	49.3
	7/8	249	453	46.2	490	49.9
24		290	531	54.1	572	58.3
	1	325	591	60.2	640	65.2
26		340	621	63.3	661	67.4
28		394	720	73.4	788	80.3
	1-1/8	411	748	76.2	810	82.6
30		453	827	84.3	904	92.2
32	1-1/4	515	944	96.2	1040	106
35	1-3/8	616	1120	115	1220	124
36		652	1190	121	1290	131
38	1-1/2	726	1330	135	1440	146
40		805	1450	151	1590	162
42		887	1490	151	1620	165
44		974	1620	165	1780	181
	1-3/4	994	1650	168	1800	183
46		1060	1770	180	1930	196
48		1160	1940	197	2120	216
50		1260	2080	212	2300	234
	2	1300	2150	219	2380	242
52		1360	2260	230	2450	249

* Mass per unit length of POWERFORM 35P increases by approx. 3%

Note: POWERFORM 35P is available on special request and prior confirmation.
Rope Sizes and Breaking Force not shown in the standard table, may be available on request and prior confirmation.
