Powerform 8 PC

Powerform^® 8P is a high strength eight strand rope plastic impregnated ideal for situations where longer service life is required.
High fatigue life resulting from the unique compaction process.
Maximum resistance to crushing. Recommended for multi-layer spooling operations.
Increased abrasion resistance resulting from the unique compaction process.
Greater surface contact area resulting from the eight strand construction and compacted finish give longer rope life and reduced sheave wear.
Fully lubricated in manufacturing.
Optional plastic impregnation of the steel core. (P) signifies full plastic impregnation of the steel core.

Powerform 8 PC

Standard Characteristics Powerform^® 8/8P
Compacted	Yes	No
Compacted	■
Grade	1960	2160
Grade	■
Finish	Bright	Galvanised
Finish	■	■
Lay Direction	Right Hand	Left Hand
Lay Direction	■	■
Lay Type	Ordinary	Langs
Lay Type	■
Nominal Fill Factor	0.655
Turn value at 20% of Breaking force degrees/ ‘6.5d’	94
Discard Criteria	Refer to ISO 4309:2019

Warning: Powerform•^® in Langs lay must only be used in applications where both ends are secured and are unable to rotate.

NOMINAL ROPE DIAMETER		APPROX. MASS	MINIMUM BREAKING FORCE
			GALVANISED & UNGALVANISED
			ROPE GRADE
			1960		2160
mm	in	kg/100m	kN	tonnes	kN	tonnes
10		46.0	87.8	9.0	94	9.6
11		55.7	106	10.8	114	11.6
12		66.2	126	12.8	135	13.8
	1/2	74.2	142	14.5	152	15.5
13		77.7	148	15.1	159	16.2
14		90.2	172	17.5	184	18.8
15		104	198	20.2	211	21.5
16	5/8	118	225	22.9	241	24.6
17		133	254	25.9	272	27.7
18		149	284	29.0	304	31.0
19	3/4	166	317	32.3	339	34.6
20		184	351	35.8	376	38.3
22		223	425	43.3	455	46.4
	7/8	227	434	44.2	464	47.3
24		265	506	51.6	541	55.1
	1	297	567	57.8	606	61.8
26		318	594	60.6	635	64.7
28		368	688	70.1	737	75.1
	1-1/8	384	717	73.1	767	78.2
30		423	790	80.5	846	86.2
32	1-1/4	481	899	91.6	960	97.9
34		543	1013	103	1083	110
36		609	1138	116	1218	124
38	1-1/2	679	1268	129	1357	138
40		752	1405	143	1503	153
42		847	1535	156	1651	168
44		929	1700	173	1819	185
	1-3/4	948	1735	177	1856	189
46		1016	1858	189	1985	202
48		1106	2023	206	2162	220
50		1200	2200	224	2349	239
	2	1239	2266	231	2425	247
52		1298	2374	242	2541	259

* Mass per unit length of POWERFORM 8P increases by 3%

Note: Rope Sizes and Breaking Force not shown in the standard table, may be available on request and prior confirmation.
POWERFORM 8P is available for rope diameter 16 mm and above on special request and prior confirmation.
