VESDA-E VEU Aspirating Smoke Detector (Highest Sensitivity ASD)
A range of revolutionary new features of VESDA-E VEU Aspirating Smoke Detector provides unsurpassed detection performance, flexibility, field programmability, connectivity and reduced total cost of ownership.Flair Detection Technology forms the core of the VESDA-E VEU, providing higher stability and increased longevity. Direct imaging of the sampled particles using a CMOS imager combined with multiple photo-diodes allows better detection and fewer nuisance alarms.VESDA-E VEU features a robust IP40-rated enclosure and is equipped with a powerful aspirator that provides a total pipe length of 800 m (2,625 ft). VESDA devices communicate on VESDAnet which provides a robust bi-directional communication network allowing continued redundant operation even during single point wiring failures. VESDAnet enables primary reporting, centralized configuration, control, maintenance and monitoring.VESDA-E detectors offer Ethernet and WiFi connectivity as standard features.
- Features
- Flair detection technology delivers reliable very early warning in a wide range of environments with minimal nuisance alarms
- Short wavelength laser-based detection:
- High sensitivity from small particle light scattering
- No drift compensation required since focused light directed at target gives low backgrounds
- High stability with temperature and time
- Multi stage filtration and optical protection with clean air barriers ensures lifetime detection performance
- Four alarm levels and an ultra wide sensitivity range deliver optimum protection for the widest range of applications
- Intuitive LCD icon display provides instant status information for immediate response
- Flow fault thresholds per port accommodate varying airflow conditions
- Smart on-board filter retains dust count and remaining filter life for predictable maintenance
- Extensive event log (20,000 events) for event analysis and system diagnostics
- AutoLearn smoke and flow for reliable and rapid commissioning
- Referencing to accommodate external environmental conditions to minimise nuisance alarms
| Supply Voltage | 18-30 VDC (24 V Nominal) | |||||||||||||
| Power Consumption @ 24VDC |
VEU-A00 | VEU-A10 | ||||||||||||
| Aspirator Setting | 1 | 5 | 10 | 1 | 5 | 10 | ||||||||
| Power (Quiescent) | 7.0 W | 8.8 W | 14.7 W | 8.2 W | 10.0 W | 15.8 W | ||||||||
| Power (In Alarm) | 7.8 W | 9.6 W | 15.5 W | 10.4 W | 11.6 W | 16.6 W | ||||||||
| Dimensions (WHD) | 350 mm x 225 mm x 135 mm (13.8 in x 8.9 in x 5.3 in) | |||||||||||||
| Weight | 5.3 kg (11.7 lbs) | 5.3 kg (11.7 lbs) | ||||||||||||
| Operating Conditions | Ambient: 0°C to 39°C (32°F to 102°F) Sampled Air: -20°C to 60°C (-4°F to 140°F) Tested to: -20°C to 55°C (-4°F to 131°F) UL: -20°C to 50°C (-4°F to 122°F) Humidity: 5% to 95% RH, non-condensing |
|||||||||||||
| Maximum area of coverage | 6,500 m² (69,965 sq.ft)* | |||||||||||||
| Minimum airflow per pipe | 15 l/m | |||||||||||||
| Pipe lengths depending on number of pipes in use |
|
|||||||||||||
| Maximum pipe lengths | Total Pipe Length (with branches): 800 m (2625 ft) | |||||||||||||
| StaX | PSU, Auto Pipe Clean | |||||||||||||
| No. of holes (A/B/C) | 80/80/100 | |||||||||||||
| Computer design tool | ASPIRE | |||||||||||||
| Pipe | Inlet: External diameter 25 mm or 1.05 in (3/4 in IPS) Exhaust: External diameter 25mm or 1.05 in (3/4 in IPS) via adaptor |
|||||||||||||
| Relays | 7 programmable relays (latch or non-latch states) Contacts rated 2 A @ 30 VDC (Resistive) |
|||||||||||||
| IP rating | IP40 | |||||||||||||
| Cable access | 4 x 26 mm (1.02 in) cable entries | |||||||||||||
| Cable termination | Screw Terminal blocks 0.2–2.5 sq mm (24–14 AWG) | |||||||||||||
| Dynamic Range | 0.0000%/m to 32%/m (0.0000%/ft to 10%/ft) | |||||||||||||
| Sensitivity Range | 0.001% - 20.0% obs/m (0.0003 to 6.25% obs/ft) | |||||||||||||
| Threshold setting range | Alert: 0.001%-2.0% obs/m (0.0003%-0.625% obs/ft) Action: 0.001%-2.0% obs/m (0.0003%-0.625% obs/ft) Fire1: 0.001%-2.0% obs/m (0.0003%-0.625% obs/ft) Fire2: 0.001%-20.0% obs/m (0.0003%-6.25% obs/ft) |
|||||||||||||
| Software features | Event log: Up to 20,000 events Smoke level, user actions, alarms and faults with time and date stamp AutoLearn: Detector learns Alarm Thresholds and Flow Fault thresholds by monitoring the environment. |
|||||||||||||
* System design and regulatory requirements may restrict the monitoring area to a lesser amount.
