Features And Benefits
- Cavity free
- 360° degree port lip design to ensure sleeve containment
- No cold-flow, deformation, or rotation of the sleeve
- Large shut-off area to assure long-lasting in-line sealing
- Easy in-line adjustability
- No seizing. No sticking
- Combining high alloy wetted surfaces with flanges and covers in standard alloy
Technical Details
-
Materials Of Construction - Wide range of materials in: Nickel Alloys, Titanium, Zirconium, Tantalum, Additional materials upon request
-
Size Range - 1/2″ to 2″
-
Pressure Ratings - Class 150, 300 & 600
-
Temperature Range- -20°F up to 600°F (ASME B16.34), depending on material selection
-
Body Configuration - Flanged End, Multiport, Full Port
-
Special Options - Wide range of sleeve materials, Firesafe, Cage Control Trims, Special Flanges, Different top work configurations, Actuation options
Applications
Oxidizing Media
- Wet chlorine gas
- Hypochlorites
- Calcium
- Chloride
- Sodium Hydroxide
- Chlorine
- Hydrochloric Acid
- Sulfuric Acid
- Caustics
- Acetic Acid
