Features And Benefits
- Cavity free
- 360° degree port lip design to ensure sleeve containment
- No cold-flow, deformation, or rotation of the sleeve
- Large shut-off area to assure long-lasting in-line sealing
- Easy in-line adjustability
- No seizing. No sticking
- Drain hole in the bottom of the plug with corresponding drain connetion in the valve body
Technical Details
-
Materials Of Construction - Carbon Steel, Stainless Steel, Nickel Alloys, Titanium, Zirconium, Additional materials upon request
-
Size Range - 1/2″ to 24″
-
Pressure Ratings - Class 150, 300 & 600
-
Temperature Range- -20°F up to 600°F (ASME B16.34), depending on material selection
-
Body Configuration - Flanged End, Weld End, Standard Port, Full Port
-
Special Options - Optional Bleed Valve, Wide range of sleeve materials, Fire-safe, Top work configurations Actuation
Applications
Wide range of applications, including:
- Chemicals
- Petrochemical
- Oil & Gas
- Refining
- Pulp & Paper
- Mining
- Pharmaceutical
- Food
