Features And Benefits
- Cavity free
- 360° degree port lip design to ensure sleeve containment
- No cold-flow, deformation, or rotation of the sleeve
- Large shut-off area to assure long-lasting in-line sealing
- Easy In-line adjustability
- No seizing. No sticking.
- High corrosion resistancy
Technical Details
-
Materials Of Construction - M35-1, Carbon Steel, HF Detection Paint, Additional materials upon request
-
Size Range 1/2″ to 12″*
-
Pressure Ratings - Class 300 & 600 DR
-
Temperature Range- -20°F up to 600°F (ASME B16.34), depending on material selection
-
Body Configuration- Flanged End, Screwed End, Full Port, Multiway*
-
Special Options- Wide range of sleeve materials, Top work configurations, Actuation
Applications
- Hydrofluoric Acid (HF) Alkylation
- HF Derivatives
