Features And Benefits
- Cavity free
- 360° degree port lip design to ensure sleeve containment
- No cold-flow, deformation, or rotation of the sleeve
- Large shut-off area to assure long-lasting in-line sealing
- Easy in-line adjustability
- No seizing. No sticking
- Optimized heating surface area
- Wide range of heating jacket connections
Technical Details
-
Materials Of Construction - Carbon Steel, Stainless Steel, Nickel Alloys, Additional materials upon request
-
Size Range - 1/2″ to 20″ / DN15-DN400
-
Pressure Ratings - Class 150, 300 & 600 / PN 10-40
-
Temperature Range- -20°F up to 600°F (ASME B16.34) / -100°C up to +280°C depending on material selection
-
Body Configuration - Flanged End, Weld End, Multiway, Full Port
-
Special Options - Wide range of sleeve materials, Firesafe, Top work configurations, Actuation
Applications
Particularly designed for temperature sensitive applications, such as:
- Sulfur Recovery Units
- Tail Gas
- Glue
- Bitumen
- Food
