Features And Benefits
- Equipment and Process Protection
- Low Cost Option for Horizontal Mounting
- Safety from External Leaks and Corrosion
Technical Details
-
Design Features - Fully Lined, Flange Connections ASME B16.5-Class 150, Face-to-face Dimensions Short Pattern (B16.10)
-
Materials Of Construction - Ductile Iron EN-JS 1049/60-40-18, ASTM A395, PFA Teflon Lined, 2 1 Flange Ductile Iron EN-JS 1049/60-40-18 ASTM A395, PFA Teflon Lined, 3 1 Ball Teflon PTFE solid ball
-
Size Range - 1/2″ to 12″
Applications
- Chlor-Alkali
- Industrial Inorganic Chemicals
- Metal and Mining
- Nitrogen and Phosphatic Fertilizers
- Petroleum Refining
- Pharmaceutical
