Features And Benefits
- Safe and shatter-proof, each window consists of two tempered lime glasses cemented together by a proprietary adhesive.
- The glasses are encased with a steel circumferential band.
- Fluid flow can be viewed from either top or bottom. Drip-lip feature is incorporated into the liner for immediate flow indication on low-pressure applications.
Technical Details
-
Materials Of Construction PFA fluorocarbons, PFA lined ductile iron, Ductile iron, PFA, PTFE, carbon steel, Tempered glass
-
Size Range 1/2″ to 6″I
-
Pressure Ratings To 275 PSI®
-
Temperature Range - -20°F to 300°F
Applications
- Chlorine
- Benzene
- Bromine
- Sulfuric Acid
- Nitric Acid
- Hydrochloric Acid
- Phosphoric Acid
- Sea Water
