Features And Benefits
- Live-loaded stem cartridge allows this design to achieve stringent emission standard for On-Off valves.
- No packing adjustment required during thermal cycling – performance of the valve will have no change in service.
Technical Details
-
Materials Of Construction - Carbon Steel, Stainless Steel, Nickel Alloys, Additional materials upon request
-
Size Range - 1/2″ to 12″ / DN15 to DN300
-
Pressure Ratings - Class 150 & 300 / PN10-40
-
Temperature Range- -20°F up to 500°F / -100°C up to +260°C, depending on material selection, Different packing combinations will support different temperatures
-
Body Configuration - Flanged End, Weld End, Full Port
-
Options - Wide range of sleeve materials, Firesafe, Top work configurations, Actuation
Applications
Refining
- Sulfuric Acid Alkylation
- Aromatics
- Benzene & Derivatives
- Toluene & Derivatives
